Voltage |
0.5~2.4VDC |
|
Current |
2uA-10mA |
|
Closed resistance |
<30Ω |
|
Insulation resistance |
>10MΩ |
|
Temperature range Operating |
-40℃ to 80℃ |
Product Features
Sturdy
The inductive sensor impact detection CSX-SEN-360T-30 uses an integrated die-cast aluminum alloy shell with a shell wall thickness of 3mm. The internal reinforcement rib structure design enables the product to withstand an impact force of up to 500g. This design not only enhances the rigidity of the shell, but also disperses the external impact force. Compared with ordinary plastic shell sensors, the service life in high impact environments is increased by more than 3 times.
Excellent Waterproof And Dustproof Performance
The inductive sensor impact detection CSX-SEN-360T-30 adopts the IP67 protection level standard, thanks to the double-layer O-ring and sealant potting process. The shell joints are processed with high precision, and the sealing ring forms a physical barrier. The potting glue further fills the internal gaps, which can work continuously for 30 minutes in a water depth of 1 meter without water seepage, and can effectively resist dust and water vapor erosion.
APPLICATIONS
Industrial Automation Production Line Field
In industrial automation production lines, inductive sensor impact detection CSX-SEN-360T-30 is mainly used for part position detection and counting.
Mechanical Manufacturing And Processing Field
In mechanical manufacturing and processing scenarios, inductive sensor impact detection CSX-SEN-360T-30 is responsible for monitoring tool wear and workpiece size.
Automobile Manufacturing And Assembly Field
During automobile manufacturing and assembly, inductive sensor impact detection CSX-SEN-360T-30 can be used to detect whether the installation position of automobile parts is accurate.
Logistics Warehousing And Sorting Field
In logistics warehousing and sorting systems, inductive sensor impact detection CSX-SEN-360T-30 undertakes object detection and sorting tasks.
Automated Packaging Field
In the automated packaging industry, inductive sensor impact detection CSX-SEN-360T-30 is mainly used to detect the presence of packaging materials and the filling status of products.
