China Tilt Switch Manufacturers Suppliers Factory - Customized Tilt Switch Pricelist

Your Professional Tilt Switch Supplier

Shenzhen Chengshengxing Technology Co., Ltd. is a technology-driven manufacturing enterprise specializing in the research, development, and production of micro-vibration sensors, directional sensors, tilt switches, vibration switches, ball switches, and other related products. Our offerings find extensive application in automotive electronics, intelligent digital devices, smart wearables, household appliances, industrial automation, and other fields that require precise detection of vibrations, tilts, angles, or directions.

Advanced Technology

By innovatively utilizing new materials and processes, our company has become the world's pioneer in applying hardware coating technology to the manufacturing of sensor switches.

Advanced Equipment

In response to the rapidly growing market demand, we have introduced and customized automation equipment across various production stages to enhance production management and quality control.

Brand Recognition

We have established ourselves as a preferred supplier of sensor switches for leading domestic brands such as Xiaomi and Midea. Moreover, we have successfully integrated into the supply chains of renowned international brands like Microsoft, Philips, and Bosch.

Independent Innovation

Through years of independent innovation and research and development, it has broken through the bottleneck of traditional technology.

Tilt Protection Switch CSX-SEN-645B
When the switch is perpendicular to the ground, it remains in a stable normally open state (OFF). When the switch tilts towards any direction and reaches the transition angle, its internal...
$ 0.25 read more
Inductive Sensor Impact Detection CSX-SEN-360T-30
When the switch is soldered above the PCB and in a horizontal position, it remains stable in the normally open state (OFF). When the switch tilts in any direction and reaches the switching angle,...
$ 0.28 read more
Angle Switch Sensors CSX45
When the character side of the switch is facing up and in a horizontal position, the switch remains in a stable normally open state (OFF). When the switch tilts in any direction to reach the...
$ 0.22 read more
Contact Ball Sensor BT45
This series of tilt switches is designed to be normally closed. When the character side of the switch is facing upwards and in a horizontal position, the switch remains in a stable normally closed...
$ 0.28 read more
4 Way Toggle Switch S04
Vertical four-way tilt switch (normally closed)
It is suitable for four-direction rotation detection in the vertical state of the PCB, as well as flip detection in the up, down, left, and...
$ 0.22 read more
Photoelectric Inclination Switch Stable And Reliable
This series of photoelectric tilt switches features a normally open design. When the side with characters faces up, the switch remains in a stable, normally open, high-level state (OFF). When the...
$ 0.50 read more
Tilt Roll Ball Switch CSX-SEN-645A-D
When the circuit remains normally open in an upright state and tilts or flips in any direction beyond the transition angle, it triggers the circuit to conduct, Applicable to P. C. B is in a...
$ 0.28 read more
Shock Sensor Motion Detection CSX-SEN-350A
The circuit is in a disconnected state within the range of 0-90 °, and in a conductive state within the range of 90-180 °.
The horizontal position of the switch is the critical point for...
$ 0.28 read more
Angle Transmitter X65
This series of tilt switches is based on a flexible design that can achieve angle detection or direction recognition in different application scenarios. Depending on the installation status, it...
$ 0.28 read more
Unidirectional Tilt Switch S07
When the A terminal (trigger terminal) of the switch is within the range of 0-90 °, the circuit is generally in a disconnected state. When the A terminal (trigger terminal) is within the range of...
$ 0.30 read more
Tilt Switch Power-off Protection S07D
When the A terminal (trigger terminal) of the switch is within the range of 0-90 °, the circuit is generally in a disconnected state. When the A terminal (trigger terminal) is within the range of...
$ 0.30 read more
Angle Switch Angle Detection CSX-SEN-815A
When the A terminal (trigger terminal) of the switch is within the range of 0-90 °, the circuit is generally in a disconnected state. When the A terminal (trigger terminal) is within the range of...
$ 0.26 read more

First 12 3 Last

Specification of Tilt Switch

Voltage	0.5~2.4VDC
Current	2uA-10mA
Closed resistance	<30Ω
Insulation resistance	>10MΩ
Temperature range Operating	-40℃ to 80℃

Types of Tilt Switch

The tilt switches produced by our company mainly include the following types:

One-Way Tilt Switch

When the A terminal (trigger terminal) of the switch is within the range of 0-90 °, the circuit is generally in a disconnected state. When the A terminal (trigger terminal) is within the range of 90 ° -180 °, the circuit remains in a conducting state.

Two-Way Tilt Switch

Two-way tilt switch refers to a tilt sensor that can detect tilting motion in two directions, typically meaning it can sense tilt along both the pitch (forward/backward) and roll (left/right) axes, essentially allowing it to register a tilt event regardless of which direction the object is tilted within its specified range; it's essentially a dual-axis tilt switch.

4 Way Tilt Switch

Applicable to P C. B is a 4-way rotation detection or flipping detection in the up, down, left, and right directions when looking straight, and can also recognize single direction tilt angles.

6 Way Tilt Switch

Pure mechanical design, multifunctional 6-way detection or attitude recognition, miniature, intelligent, and energy-saving, is a low-cost alternative to gyroscopes.

Omnidirectional Tilt Switch

This tilt switch features a symmetrical end cap design with a precision V-shaped angle guide hole, ensuring that the ball can roll flexibly and consistently in any tilt direction. The body is made of explosion-proof metal tube and covered with high insulation and corrosion-resistant nano coating, which can operate safely and stably in various harsh environments.

Applications of Tilt Switch

Industry	Application	Description
Automotive Industry	Rollover Detection	Tilt switches are integrated into rollover detection systems. If the car tilts past a specific angle, the switch activates safety measures, such as deploying airbags.
Automotive Industry	Security Alarms	Car alarms with tilt switches detect unauthorized movement, like someone lifting or towing the vehicle, triggering the alarm to deter theft.
Industrial Machinery	Safety Systems	Tilt switches prevent accidents by shutting down the equipment if it tilts beyond safe operational angles.
Industrial Machinery	Operational Control	Tilt switches help manage the orientation of machinery, such as cranes or lifts, by monitoring and controlling the tilt angle for safe operation.
Consumer Electronics	Gaming Consoles	Tilt switches in gaming controllers detect movements, translating them into actions within the game for a more interactive experience.
Consumer Electronics	Laptops and Mobile Devices	Some electronics use tilt sensors to adjust screen orientation automatically, improving usability based on the device’s position.
Safety Systems	Tamper Detection	Tilt switches detect if a security device, such as a camera or alarm, is moved or tampered with, triggering alerts or alarms.
Safety Systems	Overturn Protection	Household appliances like space heaters incorporate tilt switches to shut off power if the device tips over, reducing fire hazards.
Home Appliances	Automatic Shut-off for Safety	Appliances such as electric kettles and heaters are equipped with tilt switches that power off if the appliance is knocked over, preventing overheating or fire.

Key Differences: Tilt Switch vs. Mercury Switch

Feature	Tilt Switch	Mercury Switch
Sensitivity	Moderate sensitivity, ideal for basic tilt applications	High sensitivity, suitable for precision-based applications
Material	Non-toxic materials; generally made from metal or plastic	Contains mercury, a toxic substance, which requires careful handling
Durability	Highly durable with minimal risk of leakage	Enclosed in glass or metal, which can be more fragile
Environmental Impact	Environmentally safe and easy to dispose of	Hazardous to the environment due to mercury content
Applications	Commonly used in consumer electronics and alarm systems	Best for thermostats, sensitive industrial equipment, and specific medical devices

Ordering Process

productcate-1187-299

The initial and critical step entails an in-depth consultation with clients to comprehensively understand their specific requirements, preferences, and expectations. Once these requirements are clearly delineated, the process proceeds to sample confirmation.

In this phase, a prototype is developed according to the client's specifications and submitted for approval. This ensures that the final product will align with the client's expectations regarding quality, design, and functionality. Upon approval of the sample, the process advances to order placement and payment.

Clients proceed to place their orders and make the required payments, thereby securing their position in the production schedule. Production then commences.

With a team of skilled artisans and state-of-the-art machinery working diligently to realize the client's vision. Upon completion of production, the items are meticulously packaged and shipped.

To their designated destination. This stage involves careful packaging to ensure the products arrive in pristine condition. Finally, the cycle concludes with receipt confirmation.

Clients are requested to confirm receipt of their order and provide feedback on the quality and punctuality of the delivery. This step not only ensures client satisfaction but also offers valuable insights for continuous improvement and future collaborations.

Packaging and Shipping

Packaging	Normally are cartons, but also we can pack it according to requirement.
Shipping	Usually by air (DHL,UPS,TNT, FedEx etc).

Our Factory

In 2008, the company was established with a strong entry into the sensing switch industry. In the same year, it launched the first micro patch vibration sensing switch, breaking the industry monopoly in Europe, America, and Taiwan.

productcate-1-1

FAQ

Q: How do I install different types of tilt switches?

A: Installation varies by tilt switch type. Mechanical and ball-and-spring tilt switches are often mounted using screws or clips on a surface. In contrast, solid-state switches may need integration with electronic circuits. Ensure proper circuit connection during installation, and consider protective measures if the switch is exposed to environmental factors or potential interference.

Q: What causes false triggering in tilt switches?

A: False triggering can occur due to environmental vibrations, temperature fluctuations, or switch malfunction. Mercury tilt switches, for example, are temperature-sensitive and are best used in stable environments. Be mindful of the installation location to avoid sources of vibration that may cause unintended activation.

Q: How can tilt switches be integrated with other sensors?

A: Tilt switches can be integrated with other sensors, such as accelerometers, to form more complex detection systems. In automotive safety systems, for instance, tilt and acceleration data may be combined to monitor tilt angles and dynamic movement. Consider interface compatibility and power requirements when integrating with other sensors.

Q: What is the typical lifespan of a tilt switch?

A: The lifespan of a tilt switch depends on its type and operating environment. Solid-state switches generally last longer than mechanical or ball-and-spring types, as they lack mechanical wear. Choosing a more durable switch type for harsh environments can help extend service life.

Q: What are common tilt switch issues and troubleshooting steps?

A: Common issues include failure to trigger, false triggering, and poor circuit contact. If the switch fails to activate, check if the tilt angle exceeds the threshold and verify the power connection. For frequent false triggers, try repositioning the switch or using a more stable solid-state type. For contact issues, clean the contact points or replace any aged circuit components as needed.

We're professional tilt switch manufacturers and suppliers in China, specialized in providing high quality customized service. We warmly welcome you to buy bulk tilt switch in stock here from our factory. Contact us for quotation.
